Soluzione avanzata di acquisizione e riproduzione con Thunderbolt 3 a 40 Gb/s, connessioni 12G-SDI e HDMI 2.0 fino a 2160p60 con RGB 12 bit e HDR via HDMI 2.0a. Design rack con codifica H.265 in tempo reale tramite encoder hardware integrato.
3469,58 €IVA inclusa
UltraStudio 4K Extreme 3 rappresenta la soluzione di acquisizione e riproduzione più avanzata al mondo per computer con PCI Express e Thunderbolt. Dispone di Thunderbolt 3 a 40 Gb/s incredibilmente veloce, connessioni avanzate 12G-SDI e HDMI 2.0 per lavorare fino a 60 fps con colori profondi, RGB a 12 bit, supporto per flussi di lavoro HDR tramite HDMI 2.0a e dimensioni dei frame 4K estremamente grandi. La più ampia gamma di connessioni analogiche e digitali rende UltraStudio 4K Extreme 3 compatibile praticamente con qualsiasi telecamera, deck, router o display. Inoltre, è supportata la codifica H.265 in tempo reale, grazie al suo encoder hardware integrato estremamente potente. Caratteristiche principali Acquisizione e riproduzione Thunderbolt 3 in un design per rack Connessioni 12G-SDI, HDMI, analogiche Ideale per montaggio e correzione colore professionali SD, HD e Ultra HD fino al 2160p 60 4:2:2 e 4:4:4, acquisizione e riproduzione 3D dual stream
| Power | 2 x built-in international AC power supply with IEC C14 inlet. 100 to 240 V, 50 to 60 Hz |
|---|---|
| Computer interface | Thunderbolt 3 (Mac OS and Windows), PCIe 4 lane generation 2 |
| SDI rates | 270 Mb/s, 1.5 Gb/s, 3 Gb/s, 6 Gb/s, 12 Gb/s |
| Analog audio inputs | 4 channels of professional balanced analog audio via XLR connectors and 2 channels of consumer unbalanced via RCA connectors |
| AES/EBU audio inputs | 2 channels unbalanced with sample rate converter on BNC connector |
| SDI audio inputs | 16 channels embedded in SD / HD / 2K / 4K |
| SDI audio outputs | 16 channels embedded in SD / HD / 2K / 4K |
| HDMI audio outputs | 8 channels embedded in SD / HD / 4K |
| SDI compliance | SMPTE 259M, SMPTE 274M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M, SMPTE 425M, SMPTE 435, SMPTE 2048-1, SMPTE 2081-10, SMPTE 2081-11, SMPTE 2082-10, SMPTE ST2108-1, ITU-R BT.656, ITU-R BT.601 |
| Internal software upgrade | firmware built into software driver. Software driver loads upgrades at system start or via updater software |
| Analog audio outputs | 4 channels of professional balanced analog audio via XLR connectors |
| SDI audio sampling | 48 kHz, 24 bit |
| HD video standards | 720 x 480p 59.94, 720 x 576p 50, 1280 x 720p 50, 1280 x 720p 59.94, 1280 x 720p 60, 1920 x 1080p 23.98, 1920 x 1080p 24, 1920 x 1080p 25, 1920 x 1080p 29.97, 1920 x 1080p 30, 1920 x 1080p 47.95, 1920 x 1080p 48, 1920 x 1080p 50, 1920 x 1080p 59.94, 1920 x |
| Ultra HD video standards | 3840 x 2160p 23.98, 3840 x 2160p 24, 3840 x 2160p 25, 3840 x 2160p 29.97, 3840 x 2160p 30, 3840 x 2160p 47.95, 3840 x 2160p 48, 3840 x 2160p 50, 3840 x 2160p 59.94, 3840 x 2160p 60 |
| Software included | DaVinci Resolve, Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS and Windows. Media Express, Blackmagic Desktop Video Utility and Blackmagic driver on Linux |
| SD video standards | 525i 59.94 NTSC, 625i 50 PAL |
| SDI video inputs | 2 x 12 Gb/s and 2 x 6 Gb/s SD / HD / 2K / 4K. Supports single, dual and quad link 4:2:2 and 4:4:4. 2D and 3D switchable |
| SDI video outputs | 2 x 12 Gb/s and 2 x 6 Gb/s SD / HD / 2K / 4K. Supports single, dual and quad link 4:2:2 and 4:4:4. 2D and 3D switchable |
| HDMI audio sampling | 48 kHz, 24 bit |
| HDMI video outputs | HDMI 2.0 type A connector with support for 2160p 60 |
| Supported codecs | AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, HEVC, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR, DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes 422 LT, Apple ProRes 422 Proxy, Uncom |
| Software applications | DaVinci Resolve, Fusion, Final Cut Pro X, Adobe Premiere Pro CC, Avid Media Composer, Adobe After Effects CC, Avid Pro Tools, Steinberg Cubase, Steinberg Nuendo, Adobe Photoshop CC, OBS Studio, Wirecast, vMix Live, Zoom, The Foundry Nuke, Grass Valley Edi |
| Color precision | 8, 10, 12-bit RGB 4:4:4 up to 3840 x 2160p 30 and 8, 10-bit YUV 4:2:2 in all standards |
| Multiple rate support | HDMI and SDI video connections are switchable between SD, HD, UHD and 4K. Component analog video connections are switchable between SD and HD |
| HDMI video inputs | HDMI 2.0 type A connector with support for 2160p 60 |
| 2K video standards | 2048 x 1080p 23.98 DCI, 2048 x 1080p 24 DCI, 2048 x 1080p 25 DCI, 2048 x 1080p 29.97 DCI, 2048 x 1080p 30 DCI, 2048 x 1080p 47.95 DCI, 2048 x 1080p 48 DCI, 2048 x 1080p 50 DCI, 2048 x 1080p 59.94 DCI, 2048 x 1080p 60 DCI, 2048 x 1080PsF 23.98 DCI, 2048 x |
| 4K video standards | 4096 x 2160p 23.98 DCI, 4096 x 2160p 24 DCI, 4096 x 2160p 25 DCI, 4096 x 2160p 29.97 DCI, 4096 x 2160p 30 DCI, 4096 x 2160p 47.95 DCI, 4096 x 2160p 48 DCI, 4096 x 2160p 50 DCI, 4096 x 2160p 59.94 DCI, 4096 x 2160p 60 DCI |
| SDI video sampling | 4:2:2, 4:4:4 |
| SDI color space | REC 601, REC 709, REC 2020 |
| SDI metadata support | RP-188/SMPTE 12M-2 and closed captioning |
| HDMI color space | REC 601, REC 709, REC 2020 |
| Analog video inputs | 1 x component YUV on 3 BNCs, 1 x composite NTSC/PAL on 1 BNC |
| Analog video outputs | 1 x component YUV on 3 BNCs, 1 x composite NTSC/PAL on 1 BNC |
| Copy protection | HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content |
| Sync Input | 1 x reference input. Tri-sync or black burst |
| HDR support | HDR metadata packing, HLG and PQ transfer characteristics |
| HDMI audio inputs | 8 channels embedded in SD / HD / 4K |
| MIC input | 1 x 48 V microphone input via XLR connector. Phantom power switchable via software control |
| HDMI video sampling | 4:4:4, 4:2:2, 4:2:0 |
| HDMI configuration | HDMI 2.0b supports Deep Color and HDR. Automatically configures to connected display |
